We are one of the leading manufacturer and exporter of water and geyser thermostats. The company has earned good reputation for quality, timely delivery and service wherever required. First product of the company, Stem Thermostat, 20 A, 230 V, 25 - 75°C, is ‘ISI’ marked since 1994 (License no. CM/L – 7059270 from Bureau of India Standards).

We endeavor to provide better customer satisfaction through quality products and timely delivery. Our excellence in the industry enable our clients to excel in their field of operation. Over the years, we have been catering to the requirement of a large clients base. Besides the domestic market, we also export our range of products to various countries.

Quality of products made and supplied by the company is well appreciated by customers. The company has been awarded the ISO 9001: 2008 certification in recognition of its excellence in Quality Management System.


Thermostats

Stem Type Thermostats

Thermostat with L bracketDetails Thermostat with Plain bracketDetails

We manufacture high quality precision heating thermostats with temperature variable knob and having different mounting options which are used in switchboards, cabinets, panels and enclosures.

Technical Characteristics

Stem length 175 mm
Temperature range of operation 25-75 °C (other ranges on request)
Tolerance on operating temperature Within 4 °C or Customer defined
Temperature operating point of safety Customer defined
Temperature Differential Within 10 °C; 2 pole safety has to be manually reset
Insulation Level 1 KV for 1 min
Contact Rating 20 A, 230V resistive
Contact configuration Opening on temperature rise


Bimetallic Thermostats

We manufacture high quality din rail mountable precision heating / cooling thermostats with temperature variable knob which are used in switchboards, cabinets, panels and enclosures.

Technical Characteristics

Thermostat Type Heating Thermostat Cooling Thermostat
Contact Configuration Contacts opening on temperature rise Contacts closing on temperature rise
Product Identification Red coloured knob with light grey body Blue coloured knob with light grey body
Sensor Element Thermostatic Bimetal
Temperature Range 0 to 60 °C or 30 to 140 °F
Switching Differential Less than 6 K at a temperature change of >1 K / min
Service life 100,000 cycles
Switching capacity 10 A resistive @ 250 V AC, 15 A resistive @ 120 V AC
Terminals Suitable for AWG 14 ( 2.5 mm²) wires
Mounting Clip for 35 mm DIN rail

Details




Heaters

Panel Space Heaters / Enclosure Heaters

We manufacture heaters in different ratings and sizes for enclosures, panels, cabinets & switchboards.

The heaters have the following characteristics:

• Insulation level: 2 KV for 1 min.
• Standard power tolerance : ± 3%

Construction:

• Body made of anodized heat sink grade extruded aluminium.
• High quality Kanthal resistance material is used as heating element.
• Mica is used for optimum insulation.
• Resistance element and insulation are held tight in between extruded aluminium body and squeezed.

Advantages:

• Close tolerance of electrical rating.
• Quick and uniform heating.
• Fast dissipation of heat into air.
• Withstands much higher degree of mechanical shock and vibration.
• Very good insulation resistance even in extreme humid conditions.
• Elevated body for easy passage of heat directly to air, without heating panel body.

Panel Space Heaters (End Fixing Type)

The heater is available in following lengths and electrical ratings.

Specification

Heater Length (mm) Fixing Distance (mm) Wattage (at 24, 48,110, 120, 220, 230, 240 or 250 Volts)
210 ± 1 190 ± 6 50, 60 & 80
240 ± 1 220 ± 6 30, 40, 100 & 120
270 ± 1 250 ± 6 150
300 ± 1 280 ± 6 180 & 200
330 ± 1 310 ± 6 Upto 250

Details

Panel Space Heaters (Middle Fixing Type)

The heater is available in following lengths and electrical ratings.

Specification

Heater Length (mm) Wattage (at 24, 48,110, 120, 220, 230, 240 or 250 Volts)
150 ± 1 50, 60 & 80
180 ± 1 30, 40, 100 & 120
210 ± 1 150
240 ± 1 180 & 200

Details


Panel Space / Enclosure Heaters with perforated cover

We manufacture heaters in different ratings and sizes for enclosures, panels, cabinets & switchboards.

The heaters have the following characteristics:

• Insulation level: 2 KV for 1 min.
• Standard power tolerance : ± 3%

Construction:

• Body made of anodized heat sink grade extruded aluminium.
• High quality Kanthal resistance material is used as heating element.
• Mica is used for optimum insulation.
• Resistance element and insulation are held tight in between extruded aluminium body and squeezed.
• Protective Perforated cover with high quality CED coating.

Advantages:

• Close tolerance of electrical rating.
• Quick and uniform heating.
• Fast dissipation of heat into air.
• Withstands much higher degree of mechanical shock and vibration.
• Very good insulation resistance even in extreme humid conditions.
• Elevated body for easy passage of heat directly to air, without heating panel body.

The heater is available in following lengths and electrical ratings.

Heater Length (mm) Power Cord Length Wattage (at 24, 48,110, 120, 220, 230, 240 or 250 Volts)
248 ± 2 From 0.3 mtr to 3 mtrs 30, 40, 50, 60, 80 & 100

Details


Panel Space / Enclosure Heaters with perforated cover

We manufacture heaters in different ratings and sizes for enclosures, panels, cabinets & switchboards.

The heaters have the following characteristics:

• Insulation level: 2 KV for 1 min.
• Standard power tolerance : ± 3%

Construction:

• Body made of anodized heat sink grade extruded aluminium.
• High quality Kanthal resistance material is used as heating element.
• Mica is used for optimum insulation.
• Resistance element and insulation are held tight in between extruded aluminium parts and squeezed.
• Protective Perforated cover with high quality CED coating.

Advantages:

• Close tolerance of electrical rating.
• Quick and uniform heating.
• Fast dissipation of heat into air.
• Withstands much higher degree of mechanical shock and vibration.
• Very good insulation resistance even in extreme humid conditions.
• Elevated body for easy passage of heat directly to air, without heating panel body.

Panel Space Heaters (End Fixing Type)

The heater is available in following lengths and electrical ratings.

Specification

Heater Length (mm) Fixing Distance (mm) Wattage (at 24, 48,110, 120, 220, 230, 240 or 250 Volts)
210 ± 1 190 ± 6 50, 60 & 80
240 ± 1 220 ± 6 30, 40, 100 & 120
270 ± 1 250 ± 6 150
300 ± 1 280 ± 6 180 & 200
330 ± 1 310 ± 6 Upto 250

Details

Panel Space Heaters (Middle Fixing Type)

The heater is available in following lengths and electrical ratings.

Specification

Heater Length (mm) Wattage (at 24, 48,110, 120, 220, 230, 240 or 250 Volts)
150 ± 1 50, 60 & 80
180 ± 1 30, 40, 100 & 120
210 ± 1 150
240 ± 1 180 & 200

Details


PTC Enclosure Heater Dinrail Mountable

We manufacture heaters in different ratings and sizes for enclosures, panels, cabinets & switchboards.

Details


PTC Heater With Bracket

Details


Enclosure Heater MK IV

MK IV 250 Watts

Details

MK IV 400 & 500 Watts

Details
